Product Features
Discharge Temperature Range
-20 to 60°C
Recharge Temperature Range
0 to 45°C
Superior Safety
Lithium Iron Phosphate chemistry eliminates the risk of explosion or combustion due to high impact, overcharging or short circuit situation.
Warranty
10 Year Full Warranty
Technical Details and Specifications
Specifications
Nominal Voltage
12.8V
Nominal Capacity
100Ah
Energy
1280WH
Cycle Life
>3000 to 80%
Charge Voltage
14.6
Float Voltage
13.8
Max. Discharge Current
100Ah
Peak Discharge Current
150A/5S
Max Charge Current
100A
Bluetooth Enabled
Yes
Self Heated
No
Series
Yes
Parallel
Yes
Chemistry
Lithium
Practical Uses and Applications
Electric Vehicles
Electric Mobility
Solar/Wind System
Fish Finders/Trolling Motors
UPS, Backup Power Telecommunication
Medical equipment
Size and Measurements
Length (mm/in)
260/10.23
Width (mm/in)
168/6.61
Height (mm/in)
209/8.22
Weight (kg/lbs)
12.5/27.55
