VTD12-230
The Valiant VTD series deep cycle AGM battery features special additives to the positive plate and advanced AGM separators which increase cycle life up to 70% higher compared with standard AGM batteries. This technology also provides up to 15 years of float life. The VTD series is highly suited for systems that rely heavily on battery storage power such as off-grid solar systems, RV and marine and electric vehicles. *new look coming soon!
Product Features
Thicker Plate Design
With high tin low calcium alloy
Deep Discharge Recovery
1200cycle @ 50% DOD
Longer Service Life
In both Float or Cycling Applications
High Power Density
Technical Details and Specifications
Specifications
Volts
12V
Ah @ 20 HR
230Ah
BCI Group Size
N/A
Terminal
M8
Cycle Life to 50% DOD
1100 Cycle Times
Practical Uses and Applications
Off-grid solar systems
RV and marine
UPS/Telecom
Electric Vehicle
Golf cart
Size and Measurements
Length(mm/in)
522/20.55
Width(mm/in)
240/9.44
Height(mm/in)
219/8.62
Total Height(mm/in)
223/8.77
Weight(kg/lbs)
65.3/143.96
