Product Features
Discharge Temperature Range
-20 to 60 degrees
Recharge Temperature Range
0 to 45 degrees
Superior Safety
Lithium Iron Phosphate chemistry eliminates the risk of explosion or combustion due to high impact, overcharging or short circuit situation.
Warranty
5 Year Full Warranty
Technical Details and Specifications
Specifications
Nominal Voltage
12.8V
Nominal Capacity
9AH
Energy
115.2WH
Cycle Life
>3000 to 80%
Charge Voltage
14.6V
Float Voltage
13.8V
Max. Discharge Current
10A
Peak Discharge Current
20A/3S
Max Charge Current
10A
Practical Uses and Applications
Electric Vehicles
Electric Mobility
Solar/Wind System
Fish Finders/Trolling Motors
UPS, Backup Power Telecommunication
Medical equipment
Size and Measurements
Length (mm/in)
151/5.94
Width (mm/in)
65/2.55
Height (mm/in)
95/3.74
Weight (kg/lbs)
1.2/2.4
